Dragon DN4X100 nitrous solenoid

Performancefirstcycle is proud to bring you the lightest most powerful nitrous solenoid in it's class. The DN4X100 Dragon solenoid is capable of delivering a 250 shot of nitrous while weighing in at less than 6 ounces. Specially designed for inline 4 and V8 applications while using less components for a more direct injection and less friction loss.

This solenoid has a special high amp coil and plunger combination that Performancefirstcycles developed for better progressive controller performance and quicker opening rate. This is the highest flowing  solenoid of it's size available.

We would like to remind customers that our warranty does not cover any kind of damage as a result of using unfiltered nitrous. For optimum results, the nitrous should be filtered during the bottle filling process.

Media: Nitrous oxide
Max. Pressure: 1,200 PSI
Burst Pressure: 5,000 PSI

Electrical Characteristics

Coil Voltage: 12 Volts DC
Nominal Power: 40 Watts
Coil Construction: Molded coil with 12” leads.
Duty Cycle: 15 to 50hz
Mechanical Characteristics
Material: All standard metallic interior parts are stainless steel and billet aluminum
Dimensions: 3.25” H x 1.25” D
Orifice Diameter: .100
Porting: 1/4 NPT intake and four 1/8 NPT outlets
Housing: Standard grommet
Valve Weight: 13.75 ounces
12 amp draw
