Dragon DF3X80 fuel solenoid

Performancefirstcycle is proud to bring you the lightest most powerful nitrous solenoid in it's class. The DF3X80 Dragon solenoid is capable of delivering enough fuel for a 200 shot of nitrous while weighing in at less than 6 ounces. The only fuel solenoid on the market with a built in showerhead specially for 3 and 6 cylinder applications for more direct injection while saving space,weight and components.

This solenoid has a special high amp coil and plunger combination that Performancefirstcycles developed for better progressive controller performance and quicker opening rate. This is the highest flowing  solenoid of it's size available.

Features are
Media: Fuel
Max. Pressure: 20 PSI
Burst Pressure: 5,000 PSI

Electrical Characteristics

Coil Voltage: 12 Volts DC
Nominal Power: 40 Watts
Coil Construction: Molded coil with 12” leads.
Duty Cycle: 15 to 50hz
Mechanical Characteristics
Material: All standard metallic interior parts are stainless steel and billet aluminum
Dimensions: 3.25” H x 1.25” D
Orifice Diameter: .156
Porting: 1/8 NPT intake and three 1/8 NPT outlets
Housing: Standard grommet
Valve Weight: 5.90 ounces
1.5 amp draw
