Titan TN4X125 Pro Mod Nitrous Solenoid

Performancefirstcycle is proud to bring you the Titan TN4X125 solenoid. The TN4X125 Titan solenoid is capable of delivering a 500 shot of nitrous. Specially designed for inline 4 and V8 applications while using less components for a more direct injection and less friction loss. Performancefirst produces the only solenoids on the market with built in distribution showerheads. Titan solenoids are designed with the professional racer in mind that will not compromise on horsepower. These high quality solenoids feature CNC machined billet aluminum bodies, high lift plungers for maximum flow capacity.

We would like to remind customers that our warranty does not cover any kind of damage as a result of using unfiltered nitrous. For optimum results, the nitrous should be filtered during the bottle filling process.

Media: Nitrous oxide
Max. Pressure: 1,200 PSI
Burst Pressure: 5,000 PSI

Electrical Characteristics

Coil Voltage: 12 Volts DC
Nominal Power: 60 Watts
Coil Construction: Molded coil with 24” leads.
Duty Cycle: 15 to 50hz
Mechanical Characteristics
Material: All standard metallic interior parts are stainless steel and billet aluminum
Dimensions: 3.75” H x 1.75” D
Orifice Diameter: .125
Porting: 1/4 NPT intake and four 1/8 NPT outlets
Housing: Standard grommet
Valve Weight: 13.75 ounces
16 amp draw
